Trek Top Fuel 9.8 GX AXS Gen 4 2025 Full Suspension MTB - Dark Web

Season:2025

Brand:Trek

Code:46147BLK

The Top Fuel 9.8 GX AXS Gen 4 is a lightweight carbon trail bike built to rip up climbs and stay playful on descents. It gives you the confidence you want through roots and rocks, thanks to a 120 mm/130 mm RockShox suspension package with a Pike Select+ fork and Deluxe Ultimate shock. Plus, you can shift easily even under load with an SRAM GX Eagle AXS wireless transmission.

It's right for you if...
You're after a carbon trail bike that keeps weight to a minimum without compromising on capability. You like to ride everything – long alpine climbs, rooty aspen slalom, fast XC singletrack and you want a bike that can keep up on the ups and hold its own on the downs. Keeping things light with a carbon frame is important to you, and you want the smooth-shifting performance of a direct mount transmission.

The tech you get
An OCLV Mountain Carbon frame with a 4-way Mino Link lower shock mount for tweaking geometry and suspension leverage rate. A 130 mm RockShox Pike Select+ fork with DebonAir spring, and Charger 3.1 RC2 damper, plus 120 mm of rear travel from a RockShox Deluxe Ultimate RCT shock. An SRAM GX Eagle wireless transmission, SRAM Level Bronze 4-piston hydraulic brakes, Bontrager Line dropper post and tubeless-ready Bontrager Line Comp 30 wheels.

The final word
If you're after a light carbon trail bike that balances a playful and capable ride, reach for the Top Fuel 9.8 GX AXS Gen 4. Its ultra-lightweight frame pairs with a 4-way Mino Link lower suspension mount for taking control of your geometry and suspension feel. Plus, you get a wireless SRAM GX AXS transmission and a sweet RockShox suspension package.

Why you'll love it
  • The Top Fuel Gen 4 delivers an intensely lightweight build, improved in-frame storage and more adjustability for all kinds of rides and riders
  • With 120 mm rear and 130 mm front RockShox suspension, it delivers a well-balanced ride that stays efficient on the ups and playful on the descents
  • The 4-way Mino Link makes it easy to adjust your geometry or leverage rate for how and where you want to ride
  • In-frame storage with an improved BITS bag system makes it easy to stash tools, tubes and snacks
  • It's more upgrade-ready than ever, with room for bigger 140 mm forks and longer-stroke shocks for up to 130 mm of rear travel, plus room for extra-long dropper posts
Technical Information
  • Frame: OCLV Mountain Carbon, internal storage, tapered head tube, internal guided routing, downtube guard, OCLV Next rocker link, Mino 4 link, ABP, Boost148, 120 mm travel
  • Fork: RockShox Pike Select+, DebonAir spring, Charger 3.1 RC2 damper, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 130 mm travel
  • Shock: RockShox Deluxe Ultimate RCT, 185 mm x 50 mm
  • Wheel front: Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru-axle
  • Wheel rear: Bontrager Line Comp 30, Tubeless-Ready, Rapid Drive 54, 6-bolt, Boost148, 12 mm thru-axle
  • Tyre: Bontrager Gunnison RSL XT, Tubeless-Ready, triple compound, aramid bead, 120 tpi, 27.5/29x2.40"
  • Shifter: SRAM AXS POD
  • Rear derailleur: SRAM GX Eagle AXS, T-Type
  • Crank: SRAM GX Eagle, T-Type, DUB, 30T, 55 mm chain line, 170 mm length
  • Bottom bracket: SRAM DUB MTB Wide, 73 m, BSA threaded
  • Cassette: SRAM Eagle XS-1275, T-Type, 10-52, 12-speed
  • Chain: SRAM GX Eagle, T-Type, 12-speed
  • Saddle: Verse Short Comp, steel rails, 145 mm width
  • Seatpost: S: Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 34.9 mm, 310mm length, M/ML/L/XL: Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 34.9 mm, 450 mm length
  • Handlebar/stem: Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 27.5 mm handlebar rise, 820 mm width, 0-degree stem rise, 35/45 mm stem length
  • Grips: Bontrager XR Trail Elite, nylon lock-on
  • Brake: SRAM Level Bronze 4-piston hydraulic disc
  • Brake rotor: SRAM CentreLine, 6-bolt, round-edge, 180 mm

Please Note – Whilst we endeavour to provide up-to-date information, the manufacturer's specifications and designs can change without prior notice.
Sizing Information
SizeRider HeightInseam
S

155 - 165 cm

5'1" - 5'5"

74 - 78 cm

29" - 31"

M

165 - 176 cm

5'5" - 5'9"

79 - 83 cm

31" - 33"

M/L

173 - 180 cm

5'8" - 5'11"

81 - 86 cm

32" - 34"

L

177 - 188 cm

5'10" - 6'2"

84 - 89 cm

33" - 35"

XL

188 - 195 cm

6'2" - 6'5"

89 - 91 cm

35" - 36"
